NZXT H510 Tower Case – White CA-H510B-W1

  • Iconic cable management bar and uninterrupted tempered-glass side panel
  • USB 3.2 Gen2-compatible USB-C connector on the front panel
  • Cable routing kit with pre-installed channels and straps
  • Two Aer F120mm fans and removable filter on PSU intake
  • Removable bracket designed for radiators up to 280mm
SKU: CA-H510B-W1 Categories: , ,

Specifications

Key Specs Motherboard Support Mini-ITX, MicroATX, ATX Enclosure Type Compact Mid-Tower Case Material SGCC Steel, Tempered Glass
Dimensions Height 460mm / 18.11 inches Width 210mm / 8.27 inches Depth 428mm / 16.85 inches Weight 6.6 kg / 14.55 lb
Compatibility & Clearance Max CPU Cooler Clearance 165mm Max GPU Clearance 381mm Front Fan & Radiator Clearance 60mm Cable Management 19 – 23mm
Front I/O Ports USB 3.2 Gen 1 Type-A 1 USB 3.2 Gen 2 Type-C 1 Headset Audio Jack 1
Expansion Slots Standard 7 Vertical –
Drive Bays 2.5″ 2 + 1 3.5″ 2 + 1
Fan Support Front 2 x 120mm / 2 x 140mm Top 1 x 120mm / 1 x 140mm Rear 1 x 120mm Filters All air intakes
Radiator Support Front 280mm Top – Rear 120mm
Fan Specs Model Aer P 120mm (Case Version) Speed 1,200 ± 200RPM Airflow 50.42 CFM Noise 28 dBA Fan Connector 3-pin
General Model Number CA-H510B-W1 UPC 815671014764 EAN 5060301695065



Details

This compact mid-tower is an ideal case for the majority of builds. The H510 is easy-to-build-in and offers flexibility for a variety of ATX parts.
  • Iconic cable management bar and uninterrupted tempered-glass side panel
  • USB 3.2 Gen2-compatible USB-C connector on the front panel
  • Cable routing kit with pre-installed channels and straps
  • Two Aer F120mm fans and removable filter on PSU intake
  • Removable bracket designed for radiators up to 280mm

*Case version fans and specs vary from retail version



Highlights

  • Seamless Glass Panel
  • Up to 280mm Radiator Support
  • Built-in Cable Management
Weight 0.5 kg
