Radiator Dimensions 277 x 119.6 x 27.2 mm / 10.7 x 4.7 x 1.07 inch
Pump Dimensions 89 x 75 x 40 mm / 3.5 x 2.95 x 1.57 inch
Pump MTTF >210,000 hours
Pump Noise Level 15 dBA (Max)
Pump Connector 4-Pin (PWM)
Pump Rated Voltage 12 VDC
Pump Power Consumption 6W
Fan Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
Fan Quantity 2 PCS
Fan LED Type Addressable Gen 2 RGB
Fan Speed 0-2300 RPM ± 10%
Fan Airflow 72.37 CFM (Max)
Fan Noise Level 32 dBA
Fan Pressure 2.96 mmH₂O (Max)
Fan Bearing Type ORBS
Fan Life Expectancy >160,000 Hours
Fan Power Connector 4-Pin (PWM)
Fan Rated Voltage 12VDC
Fan Rated Current 0.15A
Fan Safety Current 0.3A
RAM Clearance N/A
Series MasterLiquid Pro
Cooler Type Liquid Cooler
Radiator Size 240
Cooler Master’s Flux Series is the materialization of revolutionary cooling performance. With enhancements from the pump to the radiator and fans, the Flux Series delivers precisely tuned performance for superior heat dissipation and cooling capabilities.
PREMIUM DUAL CHAMBER PUMP
New Dual Chamber Pump more compact than before while delivering the perfect volume of flow to pressure for impressive cooling performance.
FINE TUNED PERFORMANCE RATIO
Precision engineered ultra-thin spaded fins maximize microchannels to accurately target heat spots. Enlarged copper base surface area with optimized base thickness further accelerates heat transfer.
REDESIGNED FLUX SERIES FAN
Unique air balance fan featuring interconnecting blades specifically designed for the Flux Series. Strengthened structure provides better stability for steady high speed operation. Angled inner fan frame rim boosts air intake, with frame gap generating increased air pressure for improved cooling.
DUAL LOOP ARGB PUMP
Dual loop pump ARGB with independent lighting customization showcases your visual creativity without sacrificing cooling capability.
